Automatic Single tubeTape Cutting Machine

Automatic Single Roll Tape Cutting Machine Usage: Suitable for kinds of adhesive tape,such as PVC tape/medical tape/masking tape/kraft paper/double side tape/cloth tape/BOPP tape etc. Main Technical Parameter: Feeding Width 1350mm Cutting Precision ±0.03mm 0.08mm Feeding Diameter Φ300mm Machine Speed 0 400turns/min Cutting Width 0.5mm 1350mm Voltage 380V 50HZ Feature: 1). Both Taiwan TECO A.C motor withMistubishi frequency converter andTaiwan Tatung Frequency converter with motor are employed by driven part. 2). Cutting width is positioned by Mistubishi servo motor 3). Blade feeding is operated by Mistubishi servo motor,whichappliesto automatic angle change adjustment of circular blade4). Mistubishi P.L.C with LCD touch screen for program setting and operation5). Taiwan HIWIN high precision ball screw is fixed in Sliding part and Taiwan HIWIN linear slide rail to bearthe load of the cutter seat Optional equippment: Shafts can be changed into smaller one Safe cover to protect operators Pictures: Cutting machine with 1 inch spindle Cutting machine with 3 inches spindle
